6.5kw 48v SMS hybrid inverter
Computers & Electronics
Posted 5 months ago
13 Views




New
PAY ON DELEVERY
Specifications
Category
Computers & Electronics
Sub Category
Networking products
Brand
Other
Model
inverter
Type
Other
Condition
Brand New
Description
6.5kw 48v SMS hybrid inverter high quality model with wide range of 500v DC input with 120A MPPT inbuilt charge controller
Technical Details
Rated Power 6500W (6.5kW) / 6.5kVA Battery Voltage 48VDC Nominal Output Waveform Pure Sine Wave Max PV Input Power Up to 7800W or 8500W depending on model variant Max PV Input Voltage (VOC) 500VDC to 550VDC MPPT Voltage Range 60VDC to 450VDC or 90VDC to 500VDC depending on model variant Max Solar Charging Current 120A to 160A depending on model variant Max AC Charging Current 100A Surge Power ~12400VA for 5 seconds (double the rated power) Peak Efficiency Up to 97% (DC/AC conversion) Operating Modes Configurable for Solar-first, Utility-first, or SBU (Solar-Battery-Utility) operation Communication RS232, USB port, optional WiFi/GPRS monitoring Parallel Function Supports parallel connection for increased capacity (up to 6 or 9 units, depending on the specific model) Transfer Time 10ms (typical for UPS mode) to 20ms (for appliance mode)
